電性數據Electrical Date
多晶Poly
|
JYG-026
|
額定峰值功率Nominal peak power(Pmax)
|
8.25W
|
最大功率電壓Operating Voltage(Vmp)
|
18V
|
最大功率電流Operating Current(Imp)
|
0.458A
|
短路電流Short-circuitcurrent(Isc)
|
0.513A
|
開路電壓Open-cicuit Voltage(Voc)
|
21.6V
|
電池片最優效率Optimized cell efficiency
|
16.5%-17%
|
工作范圍Limits
工作溫度Operating temperature
|
-40°C to +85°C
|
最大系統電壓Maximum system voltage
|
1000VDC
|
溫度系數Temperature and Coefficients
NOCT
|
48°C+/-2°C
|
電流溫度系數Current temperature coefficient
|
%/K
|
0.06+/-0.01
|
電壓溫度系數Voltage temperature coefficient
|
mV/K
|
-(78+/-10)
|
功率溫度系數Power temperature coefficient
|
%/K
|
-(0.5+/-0.05)
|
其它數據Additional Data
太陽能板類型
Style of solar panel
|
Grass laminated
|
尺寸Dimensions(MM)
|
L*W*H: 200*300*2.5MM
|
凈重Weight(KG)
|
8.25W:150G
|
集裝箱裝載Container Loading
|
|
保修期限Warranty Period
|
Replacement for manufacturing defects within 1 years
|
認證Certificates
|
CE,RoHS,FCC
|
電池片Cells
|
Polycrystalline silicon photovoltaic cell
|
STC：AM1.5，1000W/㎡,working temperature ：25℃，
Humidity：＜80%，
