| 單晶Mono
|
HNT-100W
|
HNT-120W
|
| 額定峰值功率Nominal peak power(Pmax)
|
100
|
120
|
| 最大功率電壓Maximum Power Voltage(Vmp)
|
18
|
18
|
| 最大功率電流Maximum Power current(Imp)
|
5.56
|
6.67
|
| 短路電流Short-circuitcurrent(Isc)
|
6.20
|
7.45
|
| 開路電壓Open-cicuit Voltage(Voc)
|
21.6
|
21.6
|
| 電池片最優效率Optimized cell efficiency
|
16%-17%
|
16%-17%
|
工作范圍Limits
| 工作溫度Operating temperature
|
-40°C to +85°C
|
| 最大系統電壓Maximum system voltage
|
1000VDC
|
溫度系數Temperature and Coefficients
| NOCT
|
48°C+/-2°C
|
| 電流溫度系數Current temperature coefficient
|
%/K
|
0.06+/-0.01
|
| 電壓溫度系數Voltage temperature coefficient
|
mV/K
|
-(78+/-10)
|
| 功率溫度系數Power temperature coefficient
|
%/K
|
-(0.5+/-0.05)
|
其它數據Additional Data
| 電池片的數量和排列方式
Number of cells
and type of connection
|
|
| 尺寸Dimensions(MM)
|
L*W*H:995*808*35
L*W*H:1150*808*35
|
| 凈重Weight(KG)
|
100W:12KG
120W:12.5KG
|
| 集裝箱裝載Container Loading
|
|
| 輸出功率Guaranteed Power Output
|
15 year:90% of
its nominal power rating
|
| 25 yesr:80% of
its nominal power rating
|
| 保修期限Warranty Period
|
Replacement for
manufacturing defects within 5 years
|
| 認證Certificates
|
CE,RoHS,FCC
|
| 電池片Cells
|
Monocrystalline
silicon photovoltaic cell
|
測試條件：光強：AM1.5，1000W/㎡,環境溫度：10-35℃，
相對濕度：＜80%，
