電性數據Electrical Date
| 多晶Poly
|
JYG-021
|
| 額定峰值功率Nominal peak power(Pmax)
|
0.3W
|
| 最大功率電壓Operating Voltage(Vmp)
|
4V
|
| 最大功率電流Operating Current(Imp)
|
0.075A
|
| 短路電流Short-circuitcurrent(Isc)
|
0.0825A
|
| 開路電壓Open-cicuit Voltage(Voc)
|
4.8V
|
| 電池片最優(yōu)效率Optimized cell efficiency
|
16.5%-17%
|
工作范圍Limits
| 工作溫度Operating temperature
|
-40°C to +85°C
|
| 最大系統電壓Maximum system voltage
|
1000VDC
|
溫度系數Temperature and Coefficients
| NOCT
|
48°C+/-2°C
|
| 電流溫度系數Current temperature coefficient
|
%/K
|
0.06+/-0.01
|
| 電壓溫度系數Voltage temperature coefficient
|
mV/K
|
-(78+/-10)
|
| 功率溫度系數Power temperature coefficient
|
%/K
|
-(0.5+/-0.05)
|
其它數據Additional Data
| 太陽能板類型
Style of solar
panel
|
PET laminated
|
| 尺寸Dimensions(MM)
|
L*W*H: 35*67*3.0MM
|
| 凈重Weight(KG)
|
0.3W:8G
|
| 集裝箱裝載Container Loading
|
|
| 保修期限Warranty Period
|
Replacement for
manufacturing defects within 1 years
|
| 認證Certificates
|
CE,RoHS,FCC
|
| 電池片Cells
|
Polycrystalline
silicon photovoltaic cell
|
STC：AM1.5，1000W/㎡,working temperature ：25℃，
Humidity：＜80%，
