品牌：RETZ瑞茨/我們一直致力于流體控制和測控領域的持續創新，始于2005……進口氣控式脈沖閥更改了脈沖閥的驅動方式，與遠程先導控制盒連接，從而實現集中控制，露天防水的目的，也越來越受國內外市場的喜愛。遠程先導控制盒安裝在脈沖閥的上部中間位置，連接尼龍氣管不超過2米，兩頭都配直通氣管接頭RETZ The
pneumatic pulse valve has changed the driving mode of the pulse valve and is
connected to a remote pilot control box, achieving centralized control and
outdoor waterproofing. It is also increasingly popular in domestic and foreign
markets. The remote pilot control box is installed in the middle of the upper
part of the pulse valve. The nylon air pipe is not more than 2m long. Both ends
are equipped with straight air pipe connectors
進口直通式電磁脈沖閥材質說明/Material
Construction
閥體Body：ADC12鋁合金 ADC12 die cast
先導組件Armature：430FR不銹鋼等材料 430FR stainless
steel
膜片Diaphragm：丁晴橡膠或氟橡膠 Nitrile or Viton
彈簧Spring：321不銹鋼 321stainless
steel
緊固件Fasteners：302不銹鋼 302stainless
steel
進口直通式電磁脈沖閥技術參數Technical
Parameter
設計壓力Design
Pressure：0.2~0.8MPa
工作壓力Working
Pressure：0.3~0.6MPa
環境溫度Ambient
Temperature：常溫：-25~60℃低溫高溫可定制Customized for
Lower or Higher Temperature
相對濕度Relative
Humidity：≤85%
使用介質Working
Medium：清潔空氣Clean
Air
電壓Voltage：AC220VIAC110V/AC24V/DC24V/DC12V
Customized
防護等級Protection
Class：IP65
RETZ電磁脈沖閥是一種專為布袋式除塵器配套使用而設計的專用電磁閥，產品函蓋了直角式電磁脈沖閥、淹沒式電磁脈沖閥、直通式電磁脈沖閥、氣控脈沖閥、活塞式電磁脈沖閥、防爆系列脈沖閥等多種規格
