technical characteristics |
Technical data |
工作電流Rated current: |
16A(2.5mm2,AWG14),30A(4.0mm2,AWG12),52A(6.0mm2,AWG10) |
額耐電壓Rated Voltage: |
1000V(IEC/CEI), 600V/1000V(UL) |
接觸電阻 Contact resistance: |
<5mΩ |
絕緣電阻 Insulation Resistance: |
>500MΩ |
適配電線規格 Suitable cable cross sections: |
2.5mm2、4mm2、6mm2 10AWG、12AWG、14AWG |
阻燃等級Flame class |
UL94-V0 |
環境溫度 Ambient temperature: |
-40℃~+95℃(IEC) |
溫度上限Upper limiting temperature |
110℃ |
防護等級Protection grade: |
IP2X/IP67 |
安全等級 Security level: |
Ⅱ |
絕緣材料Insulation material |
PPO、PC、PA |
螺帽鎖緊力Nut cap locking force |
2.0-2.5NM |
插入力/撥出力Insertion force/Withdrawal force |
≤50N / ≥50N |
