上海市南森絕熱科技有限公司

上海南森絕熱科技有限公司，位于“東方巴黎”美稱的中國經濟和金融中心上海，坐落于奉賢化學工業園區，是國內最早系統地從事“可拆卸工業保溫套”的研發、生產的企業。公司成立的初衷只為解決化工企業的閥門和設備異形部位保溫臟、亂、差及需拆卸檢修難題，經過多年發展，公司引進先進設備，秉承專業的理念，從“現場測繪→設計→制作→安裝”等全部生產工序均由上海南森公司自行完成。本公司主要以“中高檔可拆卸工業保溫套”為主導，以“出口海外市場”為主要渠道，公司注冊的“Nansen”商標在國內外設備隔熱領域具有很高的知名度。

在Nansen我們總是不斷的開發新產品。產品不斷的創新和改進的過程使我們的產品能滿足更苛刻的異形部件高溫環境的保溫要求。我們總是不斷地在與客戶溝通：“Nansen如何能幫助您解決在生產中遇到的異形高溫設備保溫難題？”從而更有效的解決我們客戶在生產中遇到的挑戰。上海“智”造，銷往全球。

Nansen優越的工程背景和生產工藝，使我們可以在1-3天內為客戶提供適合您要求的樣品進行測試。從客戶提供問題-方案-樣品-解決的全程服務。

根據能量守恒定律，“Nansen可拆卸工業保溫套”阻止不必要的能量損耗，降低水、電、蒸汽能耗成本，隱形幫助增加客戶利潤，在您開源的同時我們能為您做到更好的節流。閥門等異形設備部件系熱力系統中一個重要的發熱部位，但是又往往是管線中一個薄弱和特別需要關注的部位，有更高的維修或更換頻率，在檢修進行拆裝時，傳統安裝的保溫材料成為對設備進行維護的難點，不得不請施工隊重新做保溫，造成四個方面的浪費：費物（拆下來的廢棄保溫材料）、費時（拆裝保溫需要較長工作時間）、費力（拆除或安裝傳統保溫材料時產生對人體有害的纖維刺激），費錢（重復做保溫每次都需要一筆很大浪費）。

NANSEN開發了可以與閥門及設備一同工作的可拆卸工業保溫套，可完全避免出現上述情況，安裝和拆卸變得更加容易，可反復使用且成本低廉，該保溫衣用材屬于輕質無石棉材料，在狹窄的區域同樣可以很好使用。無論是截止閥、球閥等均可安裝可拆式保溫衣。通常用戶提供閥門名稱和型號即可訂購相應保溫衣，特殊類型需要提供詳細規格或尺寸。

一、產品簡介：

“Nansen可拆卸工業保溫套”（也稱：保溫被，絕熱套、保溫夾克、柔性保溫衣、異形保溫），是我公司在吸收國外技術的基礎上自主開發的新一代絕熱保溫產品,填補了國內在絕熱保溫領域的空白。它采用耐高低溫、防火保溫材料；有內襯、中間保溫層、外保護層三層組成；根據閥門或設備的具體形狀及其使用環境，經過精心設計、測繪后，通過特殊工藝制作而成。它是目前高檔的閥門、設備絕熱保溫產品。它可用在不同溫度，不同形狀的閥門和各種冷熱設備的絕熱保溫。對于要經常拆卸、維修保養、清洗的閥門和設備等尤為實用。其綜合經濟效益好。是工業節能保溫更理想的選擇！

Product introduction

“Nansen removable industrial insulation covering” (which is also called temperature holding quilt, heat insulation blanket, heat insulation jacket, soft temperature holding cloth, abnormity temperature holding ) is a new generation of heating-preserving product which is exploited by our company with absorbing the most advanced technique. It fills up blank on this field all over the world.  It is sewed with internal pad, middle heat holding layer and external protecting layer. It is processed by special techniques with aboratively design and mapping according the locale size, using environment of valve and equipment. This product could be used for insulating heat and temperature keeping for different sizes of valve and other kinds of cold-heat equipment. It is practical for valve, pipeline equipment which need frequent taking-off, cleaning, repairing and maintenance which make it very economically. And it is the perfect choice for industry energy saving, temperature holding.

二、產品性能：

1、保溫效果好、耐高低溫（耐高溫300-2500℃，耐低溫-180℃）

2 、化學穩定性好，耐各種化學腐蝕；防蟲蛀、防霉變。

3、防火阻燃（防火A級不燃，GB8624-2006，德國標準DIN4102，A1級）

4、耐老化、耐氣候性

5、防水、防油：具有良好的憎水性能，防油污

Product Capability

1. Perfect heat maintenance, high&low temperature resistant. Can endure high temperature  300-2500℃ and low temperature -180℃;

2. Good chemical stability, good resistance of chemical corrosive; against pest, against mildew;

3. Fireproof (fireproof A Grade-noncombustible, GB8624-2006, Germany Grade DIN4102, A1 Grade);

4. Good endurance of aging and weather;

5. Waterproof, oil proof; High hydrophobicity, oil proof.

三、產品特點：

1 、絕熱保溫效果好，絕熱層采用耐熱纖維隔熱毯，表面毛羽豐富（類似羽絨），耐溫300-2500℃。

2、方便拆卸、易于安裝、方便清洗管道設備、方便維修保養。

3、可以反復使用、使用壽命長。

4、強度高，既柔軟又有韌性，易彎曲包扎。

5、可根據需保溫部位量身定做，加工非標產品。

6、產品適應性強：適用于不同溫度范圍，不同形狀的管道、設備。

7、環保，無污染：不含石棉及其他任何有害物質，對人和環境完全無害。

8、產品外觀漂亮整潔、表面可擦洗。

9、改善工作熱環境，防止人員燙傷。

10、降低室內溫度，便于空調降溫，提高環境舒適度。

Product Characteristics

1. Good capability of heat insulation, the heat insulation layer is made of heat insulation fiber mat, it is full of fiber, and can resist temperature of 300-2500℃.

2. Easy to take-off, easy to install, easy to wash pipeline and easy to do equipment maintenance.

3. High reusability and fine endurance.

4. High intensity, soft and pliable, very easy to bend package.

5. Customized as customers’ request according to individualized requirements.

6. Good adaptability: useful for heat preserving of different temperature and most kinds of valve, pipeline, and other equipment.

7. Environmentally-friendly, no pollution: without addition of asbestos or other harmful substance, no harm to human bodies or environment.

8. Good appearance and easy-to-clean surface.

9. Improve operators’ working environment for high-temperature parts to prevent personnel burns.

10. Lower the temperature indoors for air conditioning cooling to improve working environment.

四、產品適應性強：(和傳統保溫比較有明顯優勢）

1.可快速拆卸，可多次反復使用（傳統保溫只能一次使用）.

2. 適用于不同形狀的管道、設備，特別是對“異形件”更有優勢，甚至在傳統保溫無法做到的情況，可拆卸式柔性保溫衣也可以做到（因為傳統保溫是“硬質材料”加工而成，不易彎曲變形）.

3. 空間適應范圍廣泛，在一個空間狹小的區域也可以使用本保溫衣（套）（傳統保溫對狹小空間有時可能無法做到）

4.環境適應性強：像化工企業等一些有“腐蝕性”的環境，比傳統保溫更有優勢。（因為傳統保溫外表是鋁皮或鐵皮不耐腐蝕）

5.適用于不同溫度范圍，在-180-2500℃都可以長時間工作保護。

Good adaptability of product (have obvious advantage compared with traditional heat insulation)

1. It can be used again and again. (traditional heat insulation can be used only once)

2. Suitable for various valve, pipeline, equipment, especially for abnormity part, Nansen removable covering can be suitable but the traditional heat insulation cannot do. (as the traditional heat insulation made of hard material)

3. Can be used in most kinds of space big or small. ( traditional heat insulation hardly be used in poky space)

4. Good capability of environment adaptability, especially to the environment with “corrosive”, Nansen products have much more advantage. (Traditional heat insulation such as aluminum sheet, iron sheet cannot be erode resist)

5. Suitable for different range of temperature, from -180 to 2500℃.

五、性能指標

1.導熱系數：0.030W / M.K - 0.040W / M.K±0.005（常溫下）

2.耐高低溫：耐高溫2000-280℃，耐低溫負196℃
A）保冷型 -180攝氏度至-1℃
B）低溫型（使用溫度300℃以下）
C）中溫型（使用溫度300至600℃以上）
D）高溫型（使用溫度600℃以上）。

3.阻燃性能：不燃（防火A級，GB8624-2006，德國標準DIN4102，A1級）

4.密度：110-220Kg/m3

5.厚度：10mm、15mm、25mm、30mm直至180mm

6.吸濕率：< 5%

Capability Index

1. Thermal conductivity ratio：0.030W / M.K - 0.040W / M.K±0.005

2. High&low temperature resistance：up to 2000-280℃, low to -196℃

3. Capability of fireproof：Fireproof (fireproof A Grade-noncombustible, GB8624-2006, Germany Grade DIN4102, A1 Grade)

4. Density：110-220kg/m3

5. Thickness：10-150mm

6. Moisture rate：< 5%

六、主要應用

Nansen可拆卸工業保溫套 是目前高檔的閥門和設備保溫產品，廣泛應用于石油、化學工程、電力、化纖、冶金、建筑、船舶、輪胎、窯爐、造紙、制藥等領域的熱力設備和各種管道、暖通空調及制冷裝置。它適用于各種管道、設備絕熱保溫，是理想的管道和設備保溫產品！如管道、彎頭、法蘭、閥門、視鏡、三通、流量計、液位計、壓力表、化學反應器、實驗室儀器、設備、火電和核電汽輪機組、封頭、泵、鋼鐵廠等高溫環境下的儀表箱、熱交換器、壓縮機、柴油機、燃氣機、發動機及其它異型件保溫等。

Main Application

At present, Nansen removable insulation covering is a high-grade valve and equipment heat preserving product, and widely used in various pipeline, valves, warm ventilation air-conditioning equip, refrigeration equipment of petroleum, chemical, electricity,, filature, metallurgy, construction, shipping, tire, kiln stove, paper-making, pharmacy, etc. it is suitable for various pipeline, valve heat preserving and is an ideal pipeline, valve heat preserving material. For example, pipeline, elbow, flange, valve, tie-in of pipeline, chemical reactor, equipment, air machine of fire power or nuclear power, instrument box and exchange equipment used in high temperature environment of steel factory and other profiled part.

七、產品主要類別

上海南森絕熱科技自主開發的ABCDE五大類可拆卸保溫產品：

A.保內溫型：保“被保溫體的內部溫度”，使內部熱能不和外界產生熱交換（對流、輻射、傳遞）。保證生產的必備溫度，使內部熱量得到最大限度的利用，達到節能目的。

B.防外熱輻射型：防止強烈的外熱輻射，使外界熱量不能傳導到被保溫體內部，影響被保溫體的正常工作溫度，甚至損害設備、零部件、儀表等。

C.防凍型：防止外部低溫影響被保溫體內部的工作溫度。主要用于管道、設備、儀表、儀器的防凍及工藝穩定，所用材料及保溫套形式根據現場要求定制。

D.低溫保冷型：防止外部高溫傳遞到低溫保冷區。

E. 伴熱保溫型（加熱保溫型）：為了滿足生產工藝條件，或防止低溫防凍，需要對設備、管道等主動提供熱源加熱，同時需要外加保溫衣（套）保溫，使之保持一定的溫度。以滿足工藝、設備運行的溫度需要。

Nansen Product Category

Five main thermal insulation coverings made by Nansen:

A. Inner temperature-hold type: keep the inner temperature of the protected products, to stop heat exchange of the inner and outside energy (convection, radiation, and transfer). Keep the necessary temperature for production and maximize the energy utilization by saving energy.

B. Resisting outside-radiation type: resist strong outside heat radiation to keep the outer heat outside. Minimize harm to the equipment, part, and instruments.

C. Anti-freezing type: resisting outside low temperature impact the working temperature of protected equipments. This type is mainly used to protect pipeline, equipment, and instrument. The material used to make this covering is decided by the locale request.

D. Keeping low temperature type: keep away the outside heat transfer to the inside which may impact the low-temperature protected equipments.

E. Calefaction type: to satisfy the request of production, or resist freezing, the equipment and pipeline maybe need to be het up, meanwhile it needs to have covering to keep the temperature.

上海南森絕熱是一家高度以客戶為本的發展型企業，我們對客戶的承諾總結為三七二一服務方針：3小時提供優選方案，7天完成生產發貨，2天工程師到現場指導安裝，1年質量保障。我們對服務的追求是：永遠超越客戶的期望。

Nansen is a growing corporation that is absolutely dedicated to servicing the needs of our customers. Our commitment to worldwide customer service sums up to the service policy of Three, Seven, Two, and One: 3 hours to provide the optimum scheme, 7 days to finish the production and deliver, 2 days to have engineers provide installing instruction at equipment locale, 1 year warranty. The pursuit of our services is always exceeding customer expectations.

上海南森倡導改善更加美好的藍天、綠地、白云，真誠地邀請您加入我們。讓我們一起努力，創造更高經濟利潤的同時為我們后代留下一個更加綠色的地

球。

Shanghai Nansen pioneers for more beautiful blue sky, white clouds and green land; we sincerely invite you to join us. Let us join together to make higher economic profits and leave a greener earth for our offspring.

上海南森絕熱科技有限公司

陳董 工程師

手機：150 0037 1757

郵箱：1973957087@qq.com

上海市奉賢區化工工業園區

Shanghai Nansen Thermal Insulation Technology Co .,Ltd

Mr. Li  Engineer

Mobile phone: 15000371757

Email: 1973957087@qq.com

Fengxian Chemical Industry Park, Shanghai
